Simulation and Modeling of HVDC (VSC Focused)

On-demand Learning

This is a comprehensive introductory course designed for engineers, researchers, and students who want to build a strong foundation in HVDC transmission systems. Through a combination of theoretical insights and practical PSCAD modeling exercises, participants will develop the essential knowledge and skills needed to understand, simulate, and analyze HVDC systems.

What you will learn:

1) Fundamental Operating Principles of HVDC Systems

2) Line-Commutated Converter (LCC-HVDC): Basic working principle, rectification and inversion modes, commutation process and advantages and limitations

3) Voltage Source Converter (VSC-HVDC): Basic operating principle, PWM (Pulse Width Modulation) techniques, and advantages over LCC

4) System Components of HVDC Transmission: Transformers, valves, smoothing reactors, filters

5) Control Systems for LCC-HVDC: Current control mode, extinction angle control, DC voltage control

6) VSC-HVDC Controls: Decoupled control, PLL (Phase-Locked Loop) function

7) Modeling in PSCAD, Case Studies / Examples

Notes:

• All participants will receive digital course materials, which may include slide decks, reference guides, toolkits, and access to the session recording.

• Upon successful completion, you will earn the ElectroMentors Certificate of Completion.

• This course may be eligible for Professional Development Hours (PDHs) with engineering regulatory bodies such as EGBC, APEGA, PEO, Engineers Nova Scotia, and other similar organizations across Canada. Participants are responsible for ensuring the course content is relevant to their area of professional practice and for retaining proof of completion for audit purposes.

• Please note that all purchases are final. By registering and attending the course, you agree to ElectroMentors’ Terms and Conditions, including our rescheduling, cancellation, and refund policies. [Terms & Conditions].
